Regulator
High-Performance Gas Regulators
Our gas regulators are engineered to provide precise pressure control, ensuring a safe, reliable, and consistent gas supply across a wide range of applications. Designed for industrial, laboratory, medical, welding, research, and commercial environments, they help maintain optimal gas flow while enhancing operational safety and efficiency. Manufactured using premium-grade materials and advanced engineering standards, these regulators offer exceptional durability, corrosion resistance, and long service life. Their robust construction ensures dependable performance even in demanding working conditions. Easy to install and maintain, our gas regulators are compatible with various industrial gases, making them the ideal solution for accurate pressure regulation, maximum reliability, and uninterrupted operation.
Diffusion Registrant Double Stage SS Cylinder Regulator
Model No.: AED-162.1
Technical Specifications:
● Inlet Gauge Range: 0 to 280 Kg/CM2
● Maximum Inlet Pressure: 200 Kg/CM2
● Operating Temperature: – 40o C to 60o C
● Gauge Diameter: 21/2” Dial
● Outlet Gauge Pressures: 0 to 2.1 Kg/CM2
Model No.: AED-1607
Technical Specifications:
● Inlet Gauge Range: 0 to 280 Kg/CM2
● Maximum Inlet Pressure: 200 Kg/CM2
● Operating Temperature: – 40o C to 60o C
● Gauge Diameter: 21/2” Dial
● Outlet Gauge Pressures: 0 to 7 Kg/CM2
Model No.: AED-1616
Technical Specifications:
● Inlet Gauge Range: 0 to 280 Kg/CM2
● Maximum Inlet Pressure: 200 Kg/CM2
● Operating Temperature: – 40o C to 60o C
● Gauge Diameter: 21/2” Dial
● Outlet Gauge Pressures: 0 to 16 Kg/CM2
Piston Operated Double Stage SS Cylinder Regulator
Model No.: AED-1640
Technical Specifications:
● Inlet Gauge Range: 0 to 280 Kg/CM2
● Operating Temperature: – 40o C to 60o C
● Outlet Gauge Pressures: 0 to 40 Kg/CM2
● Maximum Inlet Pressure: 200 Kg/CM2
● Gauge Diameter: 21/2” Dial
Model No.: AED-1660
Technical Specifications:
● Inlet Gauge Range: 0 to 280 Kg/CM2
● Operating Temperature: – 40o C to 60o C
● Outlet Gauge Pressures: 0 to 60 Kg/CM2
● Maximum Inlet Pressure: 200 Kg/CM2
● Gauge Diameter: 21/2” Dial
Model No.: AED-16100
Technical Specifications:
● Inlet Gauge Range: 0 to 280 Kg/CM2
● Operating Temperature: – 40o C to 60o C
● Outlet Gauge Pressures: 0 to 100 Kg/CM2
● Maximum Inlet Pressure: 200 Kg/CM2
● Gauge Diameter: 21/2” Dial
Model No.: AED-16150
Technical Specifications:
● Inlet Gauge Range: 0 to 280 Kg/CM2
● Operating Temperature: – 40o C to 60o C
● Outlet Gauge Pressures: 0 to 150 Kg/CM2
● Maximum Inlet Pressure: 200 Kg/CM2
● Gauge Diameter: 21/2” Dial
Application
Applications of Gas Regulators
- ndustrial Gas Distribution Systems
- Welding & Cutting Operations
- Medical Gas Supply Systems
- Scientific & Research Laboratories
- Chemical Processing Plants
- Pharmaceutical Manufacturing
- Food & Beverage Processing
- Oil & Gas Industry
- HVAC & Refrigeration Systems
Benefits
Why Choose Our Gas Regulators
- Precise and Stable Pressure Control
- Safe and Reliable Gas Flow
- High Accuracy for Critical Applications
- Durable Corrosion-Resistant Construction
- Leak-Proof and Secure Performance
- Long Service Life with Minimal Maintenance
- Compatible with Multiple Industrial Gases
- Easy Installation and User-Friendly Operation
- Enhanced Workplace Safety
Technical Specifications
Detailed Technical Specifications for Precise Pressure Control and Reliable Gas Regulation
| Single Stage Regulator | Body Material | Max. Inlet Pressure Kg/Cm2 |
Max. Outlet Pressure Kg/Cm2 |
Max. Working Pressure Kg/Cm2 |
Pressure Gauge |
|---|---|---|---|---|---|
| AES-162.1 | 316SS | 280 | 0–2 | 1.5 | SS |
| AES-1607 | 316SS | 280 | 0–7 | 5.2 | SS |
| AES-1616 | 316SS | 280 | 0–16 | 12 | SS |
| AES-1640 | 316SS | 280 | 0–40 | 30 | SS |
| AES-1660 | 316SS | 280 | 0–60 | 45 | SS |
| AES-16100 | 316SS | 280 | 0–100 | 75 | SS |
| AES-16150 | 316SS | 280 | 0–150 | 112 | SS |
| Dual Stage Regulator | Body Material | Max. Inlet Pressure Kg/Cm2 |
Max. Outlet Pressure Kg/Cm2 |
Max. Working Pressure Kg/Cm2 |
Pressure Gauge |
| AED-162.1 | 316SS | 280 | 0–2 | 1.5 | SS |
| AED-1607 | 316SS | 280 | 0–7 | 5.2 | SS |
| AED-1616 | 316SS | 280 | 0–16 | 12 | SS |
| AED-1640 | 316SS | 280 | 0–40 | 30 | SS |
| AED-1660 | 316SS | 280 | 0–60 | 45 | SS |
| AED-16100 | 316SS | 280 | 0–100 | 75 | SS |
| AED-16150 | 316SS | 280 | 0–150 | 112 | SS |
| MATERIAL OF CONSTRUCTION | |||||
| BODY & BONNET: 316SS / 304SS / BRASS | VALVE BODY: 316SS | VALVE SEAL: TEFZEL | DIAPHRAGM: 316SS | |||||
| DIAPHRAGM SEAL: PTFE (TEFLON) | FILTER: SS / BRASS SINTERED | INLET CONNECTION: As per Cylinder Thread | |||||
| OUTLET CONNECTION: As per Requirement | |||||
Why Choose Chemicot Regulators ?
Where Performance Meets Precision in Gas Regulation.
Premium-Grade Constructio
Built with high-quality brass and stainless steel components.
Precision Pressure Control
Delivers accurate, stable, and consistent gas flow for reliable pressure control.
Single & Dual Stage Options
Available in versatile configurations for diverse industrial, laboratory, and commercial applications.
Leak-Proof Performance
Ensures maximum operational safety through reliable, leak-proof, and secure pressure regulation.
Trusted Quality
Manufactured to meet stringent quality standards for reliable performance.
Low Maintenance
Easy installation, simple operation, and hassle-free maintenance for enhanced user convenience.
